ชุดเซลล์เชื้อเพลิงไฮโดรเจนแบบ PEM (Proton Exchange Membrane Fuel Cell) ของ Horizon Fuel Cell Technologies ใช้ไฮโดรเจนและอากาศเป็นสารตั้งต้นเพื่อผลิตพลังงานไฟฟ้า โดยมี กำลังไฟฟ้าสูงสุด 30 W
ราคา 0.00 บาท
01 กันยายน 2569
ผู้ชม 10 ผู้ชม
H-30 Horizon Fuel Cell
Description
Product Description
Horizon’s H-30 PEM Fuel Cell System is a very light and compact system. It is applicable for various small projects with its 30 Watt air fed / air cooled, hydrogen fuel cell. The biggest advance of H-30 fuel cell is being air cooled; meaning that there is no need for water cooling systems with complex structures.Example projects are: Recharging for cell phone, power for a small RC car or boat, or just an economical way to begin experimenting with hydrogen fuel cells and their use and operation.
Includes
- Miniature electronic valve
- Control electronics
- Integrated fan and casing
- Low pressure protection
- 30W stack with blower
Technical Details
| Number of Cells | 14 |
| Rated Power | 30 W |
| Rated Performance | 7,8V @ 3.6 A |
| Hydrogen Supply Valve Voltage | 6 V |
| Purging Valve Voltage | 6 V |
| Blower Voltage | 5 V |
| Reactants | Hydrogen and Air |
| Ambient Temperature | 5 – 30 C; (41 – 86 F;) |
| Max Stack Temperature | 55 C (149 F) |
| Hydrogen Pressure | 0.45 – 0.55 Bar |
| Humidification | Self-humidified |
| Cooling | Air (integrated cooling fan) |
| Controller Weight | 90g |
| Stack Weight (with Fan & Casing) | 280g ± 30g |
| Hydrogen Flow Rate at Max Output | 0.42 L/min |
| Stack Size | 80x47x75mm |
| Hydrogen Purity Requirement | ≥ 99.995% (dry H2) |
| Start up time | ≤ 30s (ambient temperature) |
| Efficiency of System | 40% at 12V |
